MSO7000/DS7000 series is a multifunctional and high-performance digital oscilloscope designed on the basis of the UltraVision II technology developed by . Integrating 7 independent instruments into one, the MSO7000/DS7000 series is equipped with super high sample bandwidth ratio, extremely high memory depth, clear display, excellent waveform capture rate, and powerful data analysis functions. Many of its specifications have reached the top level in the industry. With sound solutions for mainframes, optional&accessories, and application software, it has aroused great attention from customers in the areas such as industrial control, power supply, and automotive electronics.

Features

• Analog bandwidth: 500 MHz, 350 MHz, 200 MHz, and 100 MHz; bandwidth upgrade option supported
• 4 analog channels, 1 EXT channel, and 16 digital channels (Option)
• Up to 10 GSa/s real-time sample rate
• Up to 500 Mpts memory depth (Option)
• High waveform capture rate (over 600,000 waveforms per second)
• Up to 450,000 frames of hardware real-time and ceaseless waveforms recording and playback functions
• Integrates 7 independent instruments into 1, including digital oscilloscope, 16-channel logic analyzer, spectrum analyzer, arbitrary waveform generator, digital voltmeter, 6-digit frequency counter and totalizer, and protocol analyzer
• A variety of serial protocol triggers and decodes
• Auto measurement of 41 waveform parameters; full-memory hardware measurement function
• A variety of math operations, built-in enhanced FFT analysis, and peak search function
• Waveform histogram analysis (standard)
• Independent search, navigation keys, and event table
• Built-in advanced power analysis software (option)
• User-defined one-key quick operation
• 10.1-inch capacitive multi-touch screen, 256-level intensity grading display, with color persistence
• Multiple interfaces available: USB HOST&DEVICE, LAN(LXI), HDMI, TRIG OUT, and USB-GPIB
• Web Control remote command
• Unique online version upgrade
• Novel and delicate industrial design, easy to operate
