Digital Oscilloscope

DHO1000U

Share On:

DHO1000 series digital oscilloscope is designed to meet the designing, debugging, and testing
requirements of the mainstream oscilloscope market. This series achieves a fast waveform capture
rate of 1,500,000 wfms/s with the UltraAcquire mode, 100 Mpts memory depth, 12-bit vertical
resolution.

Features

• Ultra low noise floor for cleaner signals, measuring small signals accurately.
• 12 bit vertical resolution.
• 70/100/200 MHz analog bandwidth (selectable), 2/4 analog channels, and 1 EXT channel.
• Up to 2 GSa/s real time sample rate.
• Max. memory depth: 100 Mpts (optional).
• Vertical sensitivity range: 500 µV/div to 10 V/div.
• Up to 1,500,000 wfms/s waveform capture rate with the UltraAcquire mode.
• 10.1” 1280×800 HD touch display.
• User friendly flex knobs, bringing smoother interaction.
• Standard photoelectric encoder operating knobs, effectively prolonging its service.
• Standard USB Device & Host, LAN, and HDMI interfaces.
