Single Phase Controlled Rectifier with Ramp Comparator Firing Scheme

Scientech 2708

Share On:







Scientech 2708 is a platform which helps Students to understand the various concepts of Ramp comparator firing scheme for Single phase controlled rectifier. 2708 is also useful for Students to understand the various rectifier configurations like half wave, full wave, bridge, symmetrical & asymmetrical configurations. This platform is provided with the built in AC & DC power supplies, sockets for making different interconnections in the circuit and exhaustive learning material.

 Features

  • Built in power supply.
  • Easy to operate and understand.
  • Firing circuits on single board.
  • Gradual firing angle control upto 180 degree.
  • Test points to observe output of different blocks.
  • On board AC sources of 15 V and 18 V.
  • On board rectifier components and load.
  • More than six experiments can be performed on single board.

Scope of Learning

  • Ramp Comparator Firing Scheme
  • Half Wave Controlled Rectifier
  • Full Wave Controlled Mid Point Rectifier
  • Fully Controlled Bridge Rectifier
  • Common Anode Configuration
  • Common Cathode Configuration
  • Asymmetrical Configuration
