Scientech 2711 is a comprehensive learning platform which is very useful for Students to understand the application of Thyristor in intensity control. Two firing methods are provided with this platform internal power attenuattor is included for observation of high voltage signals on the Oscilloscope. This platform is provided with internal AC/DC power supplies & exhaustive learning material.

 Features

• Built in Power Supply
• Easy to operate and understand
• On board two firing circuits
• Gradual firing angle control up to 180 degree
• In-built Power Isolation Circuit
• Switch for selection of firing circuit

Scope of Learning

• Study lamp dimmer using DIAC & TRIAC firing scheme
• Study lamp dimmer using UJT firing scheme
