Digital Oscilloscope

DHO1000 Series

Share On:



DHO1000 series digital oscilloscope is designed to meet the designing, debugging, and testing requirements of the mainstream oscilloscope market. Adopting the brand-new chipset “Centaurus” developed by RIGOL, this series achieves a fast waveform capture rate of 1,500,000 wfms/s with the UltraAcquire mode, 100 Mpts memory depth, 12-bit vertical resolution, all combined with excellent noise floor performance and vertical accuracy to meet your requirements for more accurate measurements, bringing extraordinary T&M experience for you.

 Features

  • Brand-new chipset Centaurus developed by RIGOL
  • Ultra-low noise floor for cleaner signals, measuring small signals accurately
  • 12-bit vertical resolution[1]
  • 70/100/200 MHz analog bandwidth (selectable), 2/4 analog channels, and 1 EXT channel
  • Up to 2 GSa/s real-time sample rate
  • Max. memory depth: 100 Mpts (optional)
  • Vertical sensitivity range: 500 ?V/div to 10 V/div
  • Up to 1,500,000 wfms/s waveform capture rate with the UltraAcquire mode
  • 10.1” 1280*800 HD touch display
  • User-friendly Flex Knobs, bringing smoother interaction
  • Standard photoelectric encoder operating knobs, effectively prolonging its service life
  • Standard USB Device & Host, LAN, and HDMI interfaces

 Model

Model Bandwidth Analog Channels Real-Time Sample Rate Max. Memory Depth Waveform Capture Rate Digital Channels Quote
DHO1072 70MHz 2 2GSa/s 100Mpts (opt.) 1,500,000 wfms/s
DHO1074 70MHz 4 2GSa/s 100Mpts (opt.) 1,500,000 wfms/s
DHO1102 100MHz 2 2GSa/s 100Mpts (opt.) 1,500,000 wfms/s
DHO1104 100MHz 4 2GSa/s 100Mpts (opt.) 1,500,000 wfms/s
DHO1202 200MHz 2 2GSa/s 100Mpts (opt.) 1,500,000 wfms/s
DHO1204 200MHz 4 2GSa/s 100Mpts (opt.) 1,500,000 wfms/s

Probe



Passive Probe

Model Description Manual
RP1018H 18kV 150MHz High voltage probe DOWNLOAD
RP1300H 300MHz High voltage probe (2kV) DOWNLOAD
PVP2350 350MHz, 10:1/1:1, passive high resistance probe (single strip) DOWNLOAD
RP6150A 1.5GHz Passive low resistance probe (500ohm) DOWNLOAD

Current Probe

Model Description Manual
RP1000P 4CH Power Adapter
RP1001C 300KHz, 100A DC DOWNLOAD
RP1002C 1MHz, 70ADC DOWNLOAD
RP1003C 50MHz, 30A DOWNLOAD
RP1004C 100MHz, 30A DOWNLOAD
RP1005C 10MHz, 150A DOWNLOAD
RP1006C 2MHz, 500A DOWNLOAD

High Voltage Differential Probe

Model Description Manual
PHA2150 200MHz, 1500V High Voltage Differential Probe
PHA1150 High voltage differential probe, DC-100MHz, 1500V DOWNLOAD
PHA0150 High voltage differential probe, DC-70MHz, 1500V DOWNLOAD
RP1100D 100MHz, 6.5KV DOWNLOAD
RP1050D 50MHz, 6.5KV DOWNLOAD
RP1025D 25MHz, 1.4KV DOWNLOAD
