Digital Oscilloscope

The MHO2000 series is a high-resolution 4-CH digital oscilloscope designed for the vast
mainstream digital oscilloscope market to meet the design, debugging, and test demands. It is self-developed Centaurus technical platform. Its 1,000,000 wfms/s waveform capture rate (in fast recording mode), 500 Mpts memory depth, 12-bit resolution, excellent noise floor and vertical measurement accuracy can meet the test demands for higher accuracy. The MHO2000 series digital oscilloscope supports AFG, digital signal analysis, Bode plot, and other functions. It is powered by battery pack, applicable for various complex test
scenarios.

Product Features

• 12-bit resolution
• Max. 350 MHz bandwidth, 4 analog channels, and 1 external trigger channel
• Standard configuration of 16 digital channels (required to purchase the logic analyzer probe)
• Real-time sample rate: up to 2 GSa/s
• Max. memory depth 500 Mpts
• Vertical sensitivity up to 200 μV/div
• Max. waveform capture rate of 1,000,000 wfms/s (in fast recording mode)
• Arbitrary/Function Waveform Generator (AFG)[2], power analysis, histogram, digital signal
analysis, Bode plot, and protocol decodings
• Search and navigation functions enable users to quickly search for the signals with exceptions and locate them accurately
• 256-level intensity grading display, with digital real-time fluorescence technology
• 10.1″ 1280*800 high-definition touch screen
• Brand new Flex knob brings friendly user experience
• Standard configuration of USB Device, USB Host, LAN, HDMI interfaces
• Battery pack-powered, convenient to charge anytime and anywhere, providing great feasibility for measurement
• Online upgrade
• Standard configuration of the photoelectric encoder operating knob to improve the service life of the instrument
