ADC module features AD9283 an 8-bit monolithic sampling analog-to-digital converter with an on-chip track
and hold circuit. The maximum conversion rate is at 100 MSPS, with outstanding dynamic performance over
its full operating range. This module is designed to be used with Numato Lab’s FPGA/Micro-controller boards
featuring a 2×6 pin Expansion connector. It can also be used with other boards and connector types by using
manual wiring.

Features

• Two 2×6 expansion connectors
• 8-Bit, 100 MSPS ADC
• On-Chip Reference and Track/Hold
• SNR = 46.5 dB @ 41 MHz at 100 MSPS
• Low Power: 90 mW at 100 MSPS
• Dimension: 35mm X 48mm
