USB oscilloscope

Handyscope HS4

Share On:





Handyscope HS4 USB oscilloscope
This professional powerful computer controlled USB oscilloscope features four input channels. The Handyscope
HS4 oscilloscope features a user selectable 12 bit, 14 bit or 16 bit resolution (14 bit effective, SNR 95 dB), 200 mV to
80 V full scale input range and 128 Ksamples record length per channel. Four Handyscope HS4 oscilloscope models
are available, with a maximum sampling rate of respectively 5 MSa/s, 10 MSa/s, 25 MSa/s or 50 MSa/s on all four
channels simultaneously



Hardware features

Fast Continuous streaming

Besides measuring in block mode, the Handyscope HS4 is also capable of performing continuous streaming
measurements. This will create a continuous uninterrupted data stream to the computer. The data can then be
displayed on the screen and/or saved to dis
</div

Combining multiple Handyscope HS4s



Software features

Versatile multi channel oscilloscope software
The Handyscope HS4 is delivered with the versatile multi channel oscilloscope software, which transforms the
Handyscope HS4 into an oscilloscope, spectrum analyzer, data logger, multimeter and protocol analyzer.
Some of the powerful features of the multi channel oscilloscope software are indicated below, for a full description of
the multi channel oscilloscope software, refer to the multi channel oscilloscope software pages.

Flexible signal displays

Many automatic measurements

Analyze fast serial communication protocols

24/7 Data logging



Package Contents

Item Description
Instrument Handyscope HS4
Probe 4x Oscilloscope Probe 1:1-1:10 – HP-3060
Accessories External power cable for USB port
Software For Windows 10, via website
Drivers For Windows 10, via website
Software Development Kit For Windows 10 and Linux, via website
Manuals Instrument manual and software user’s manuals, color printed and digital, via website
