Real Time Spectrum Analyzer

DSA800E series spectrum analyzers which are small, light and cost-effective, are portable spectrum analyzers designed for starters. Configured with easy-to-operate numeric keyboard, high-resolution color LCD display and various remote communication interfaces, they can be widely used in various fields, such as education, company research and development as well as industrial manufacture.

Features:

● All-Digital IF Technology
● Frequency Range from 9 kHz to 3.2 GHz
● Min. -148 dBm Displayed Average Noise Level (Typ.)
● Min. <-90 dBc/Hz @ 10 kHz Offset Phase Noise
● Level Measurement Uncertainty <1.0 dB
● 10 Hz Minimum Resolution Bandwidth
● Up to 3.2 GHz Tracking Generator (DSA832E-TG)
● Optional Preamplifier
● Advanced Measurement Functions (Opt.)
● EMI Filter & Quasi-Peak Detector Kit (Opt.)
● VSWR Measurement Kit (Opt.)
● PC Software (Opt.)
● Optional RF TX/RX Training Kit
● Optional RF Accessories (Cable, Adaptor, Attenuator, Bridge …)
● Complete Connectivity: LAN (LXI), USB Host & Device, GPIB (Opt.)
● 8 Inch WVGA (800×480) Display
● Compact Size, Light Weight Design
