Scientech 2700 High Voltage Power Electronics Lab is a compact, ready to use experiment workbench. In this particular workbench there are various applications and experiments of Power Diode and SCR on the workbench with different load configuration.

Scientech 2700 High Voltage Power Electronics Lab covers the principles and operation of Single Phase and Three Phase Thyristor control circuits.

Scientech 2700 High Voltage Power Electronics Lab has economically designed in vertical position and with sufficient space for working, this workbench is available with table and without table.

Features

• On Board (Mains) AC Power Supplies
  • Single Phase Power Supply
  • Three Phase Power Supply
• On Board  Step down AC Power Supplies
  • Single Phase Power Supply
  • Three Phase Power Supply
• MCB Protected Single and Three Phase AC Supply
• Three Phase indicator (R-Y-B) at front panel
• On Board Oscilloscope with Power Scope
• On Board DC/AC Voltmeter and DC/AC Ameter
• On Board Firing Circuits
  • Single Phase Firing Circuit
  • Three Phase Firing Circuit
  • Cycloconverter Firing Circuit
• Test point are provided to observe waveforms at different blocks in Firing Circuit
• On Board Power Devices Assembly
  • Diode Assembly
  • SCR Assembly
  • IGBT Assembly
• Internal RC snubber circuit in Power Circuit Module
• 2 mm and 4 mm Socket provided to make different connections
• Easily replaceable Firing Circuit and Power Circuit Module
• Four 200 W Bulb as Lamp Load
• Universal Motor 1/8 HP as Motor Load
• Short Circuit Protection
• Easy to operate and understand
• Exhaust fan at back panel for cooling
