Scientech 4075P Programmable Dual DC Power Supply is a versatile instrument with facility to interface with PC through USB. The front panel with keypad and cursor, makes it user friendly.
It can be set to be used as a Constant Voltage and Constant Current source. With low ripple and excellent Line and Load regulation, Scientech 4075P is fully protected against over load, over voltage, over current, over heat and short circuit.
| Specification | Value |
|---|---|
| DC Output | 2 X 0 – 30V, 2A |
| Resolution | Voltage: 100mV Current: 10mA |
| Internal Resistance | ≤10mΩ |
| Stability | 2.5 mV at 30V/2A |
| Recovery Time | ≤50μs |
| Load Regulation | ±(0.05 % + 10 mV) for 0 – 30V (A & B) |
| Line Regulation | ±(0.05 % + 10 mV) for 0 – 30V (A & B) |
| Temperature Coefficient | (0.05% + 5 mV/°C) |
| Ripple & Noise | ≤1mVrms |
| LCD Display | Color LCD Screen with backlit for voltage and current |
| Display Accuracy | (1% + 1 digit) |
| LED Indication | Glowing LED for respective output on or off |
| Interface | USB |
| Protective Modes | Overload, over voltage, over current, over heat and short circuit |
| Insulation (Chassis) | Between chassis & output terminals > 10 MΩ at 500 V Between chassis & AC plug > 50 MΩ at 500 V DC |
| General | |
| Power Supply | 230V, 10 %, 50Hz |
| Operating Temperature | 0-40°C, 80 % RH |
| Dimensions (mm) | W 285 X D 410 X H 88 |
| Weight | 6 Kg (approximately) |
| Package Contains | |
| Main Cord | 1no |
| USB Cable | 1no |
| CD (Software) | 1no |
