Circuit Design and PCB Prototyping Solutions

Tina Design Suite Circuit Design and Simulation Software with PCB Design

Tina V14 - Offline Circuit Simulation with TINA

TINA Design Suite is a powerful yet affordable circuit simulator and PCB design software package for analyzing, designing, and real time testing of analog, digital, IBIS, HDL, MCU, and mixed electronic circuits and their PCB layouts. You can also analyze SMPS, RF, communication and optoelectronic circuits; generate and debug MCU code using the integrated flowchart tool; and test microcontroller applications in a mixed circuit environment. You can analyze your circuit through more than 20 different analysis modes or with 10 high tech virtual instruments.

Tina Cloud - Online Circuit Simulation with TINACloud

With the TINACloud on-line circuit simulator, in addition to the installable versions, now you can also edit and run your schematic designs and their PCB layouts online on PCs, Macs, thin clients, tablets, smart phones, smart TVs and e-book readers without any installation. You can use TINACloud in the office, classroom, at home and while travelling, anywhere in the world that has internet access.

tina cloud - image
Learn more

PCB Prototyping Range

Time is key. That’s why we bring to you a product so simple that with a single key, you can make your prototypes only in a matter of minutes. With Scientech PCB prototyping system, we guarantee the secrecy of your designs. Our compact table-top, highly reliable machine delivers high precision PCBs in-house at an affordable cost.

PCB Prototype Machine (EP 42A)

PCB Prototype Machine

This is an environment friendly PCB Machine for each stage of PCB making and fabrication process, from design verification to structuring and board assembly. Users can produce fully functioning boards quickly and easily by drilling, engraving and routing. Auto tool change allows up to 12 tools that are automatically changed as required during production. This reduces set-up times and permits unattended production.

Benefits

  • Engrave Tool for engraving trace and pad
  • End-mill Tool for copper removing
  • Drill bit for drilling holes
  • Router Bit for PCB outline cutting
  • No pollution / environmental friendly
  • Working area : 320mm X 230mm
Learn more

Conductive ink technology based PCB Printer (V-One)

Conductive ink technology based PCB Printer

Scientech brings a compact and easy to use printer to make PCBs. Simply import your Gerber file into its software, press print, and the V-One printer will bring your board to life. Use the solder paste dispensing and reflow features to mount components onto your printed board or mount components on a pre-fabricated board with ease.

Benefits

Build your hardware easily and faster

Make PCBs on any surface

New possibilities for various applications

Learn more
