Scientech 2703 is a platform where Students can understand the various thyristor firing technique by using IC 555 and UJT. This is very useful for understanding of pulse generation. 2703 is provided with in built power supplies, sockets for making interconnection in the circuit and exhaustive learning material.

Product Features

• Built in power supply.
• Easy to operate and understand.
• Two triggering circuits on single board.
• Test points for observe output pulses.
• Sockets to make different connections.
• On board DC sources of 5 V and 12 V.

Scope of Learning

• Study of the triggering of SCR using UJT
• Study of the triggering of SCR using TC555
