This powerful USB 3.0 super speed oscilloscope combines fast sampling up to 1 GSa/s with high resolutions of 12, 14
and 16 bit and a large memory of 64 Mpoints on all four channels. The oscilloscope supports continuous streaming
measurements up to 200 MSa/s and can be synchronized with other oscilloscopes using the CMI interface to form a
multi channel combined instrument with synchronized time base. The CMI interface is available by default on the
Handyscope HS6 DIFF. Optionally, the Handyscope HS6 DIFF can be delivered with SureConnect connection test and
resistance measurement on each channel. Also, the Handyscope HS6 DIFF can be delivered with SafeGround option.
With SafeGround you can switch the differential inputs of the Handyscope HS6 DIFF into single ended inputs with
ground protection. It allows to make measurements using standard attenuating probes and protects the scope when
a short circuit to ground is created.
Do you want to use the Handyscope HS6 DIFF (remotely) via a network connection? Transform the Handyscope HS6
DIFF to a network oscilloscope using an Instrument Sharing Server with TPISS installed
</div
</div
</div
Versatile multi channel oscilloscope software
The Handyscope HS6 DIFF is delivered with the versatile multi channel oscilloscope software, which transforms the
Handyscope HS6 DIFF into an oscilloscope, spectrum analyzer, data logger, multimeter and protocol analyzer.
Some of the powerful features of the multi channel oscilloscope software are indicated below, for a full description of
the multi channel oscilloscope software, refer to the multi channel oscilloscope software pages.
| Item | Description |
|---|---|
| Carry case | Carry case BB391 |
| Instrument | Handyscope HS6 DIFF |
| Measure leads | 4 x Measure lead TP-C812B, Differential BNC -> 4 mm banana plug |
| Differential attenuator | 4 x Differential attenuator TP-DA10 |
| Alligator clips, large | Alligator Clip TP-AC80I – Set, 8 large alligator clips |
| Alligator clips, medium | Alligator Clip TP-AC10I – Set, 8 medium alligator clips |
| Alligator clips, small | Alligator Clip TP-AC5 – Set, 8 small alligator clips |
| Accessories | Handyscope / WiFiScope power supply, external power cable for USB port, Probe compensation cable TP-DB9-BNC-30 (only with option SafeGround) |
| Software | for Windows 10, via website |
| Drivers | for Windows 10, via website |
| Software Development Kit | for Windows 10 and Linux, via website |
| Manuals | instrument manual and software user’s manuals color printed and digital, via website |
