Scientech 2730 is a compact and user friendly Learning platform which is very useful for students to understand the concept of PWM generation technique, and Forward Converter topology on various load configurations. It is also helpful for understanding the Converter output on various filter configurations. Platform explains PWM generation technique, Forward converter operation, and power isolation circuit to measure the isolated output.

Features

• Easy to operate & understand
• Optically isolated PWM generation with Gate driver
• Inbuilt isolation section for measurement of the signal
• Test Points provided at output of each section to measure the signals
